Radwag UYA Ultra Microbalance

Radwag UYA Ultra Microbalance – ELLIPSIS Series

The Radwag UYA Ultra Microbalance from the ELLIPSIS Series delivers world-class weighing precision with smart automation and advanced digital features. Designed for ultra-sensitive labs—including pharma, biotech, and academic research—the UYA offers unmatched readability at 0.1 μg, real-time air buoyancy correction, and built-in system diagnostics to ensure data accuracy and compliance.

Exceptional Weighing Accuracy

• Ultra-Fine Readability: 0.1 µg resolution (0.0000001 g)
• Max Capacity: Choose from 2.1 g or 6.1 g models
• Stabilization Time: 10–20 seconds with high repeatability (down to 0.15 µg)
• Automatic Internal Calibration: Maintains accuracy in changing conditions

Smart Features & Digital Tools

• 10″ Touchscreen Display: View up to 3 panels at once—widgets, graphs, status, and history
• Voice & Light Communication: Issue voice commands or monitor via ambient light alerts
• User Verification Options: Password, RFID card, fingerprint, facial recognition, or combination
• Digital Weighing Auditor: Real-time audit trail, accuracy alerts, and air buoyancy compensation

Productivity + Compliance

• Smart Min Weight: Alerts if sample is below the USP minimum weight threshold
• ReflexLEVEL System: Fully automatic leveling for hands-free precision
• 21 CFR Part 11 Ready: Digital signature & audit support for GLP/GMP environments
• RFID Integration: Tag ingredients, products, and users for traceable workflows

Connectivity & Components

• Ports: USB-A ×2, USB-C, HDMI, Ethernet, Wi-Fi®, and Hotspot
• Included: Terminal, weighing pan(s), draft shield, brush, pincette, dust cover, power supply

Model Options

• UYA 2.5Y & UYA 2.5Y.F: 2.1 g capacity, ø16 mm pan, min weight 0.3 mg (USP)
• UYA 6.5Y: 6.1 g capacity, ø16 mm pan, min weight 0.4 mg (USP)

Key Specifications

• Readability: 0.1 µg
• Max Capacity: 2.1 g or 6.1 g (model dependent)
• Repeatability: 0.15–0.45 µg (standard)
• Linearity: ±1.5 µg
• Weighing Pan: ø16 mm
• Weighing Chamber: ø90 mm × 90 mm
• Power: 100–240V AC input, 15V DC output
• Weight: 9.1 kg net, 16.6 kg gross
• Warranty: 2 years

FAQs

Is this balance suitable for GMP/GLP labs?
Yes. It supports 21 CFR Part 11, has digital signatures, audit trails, and advanced user verification features.

What makes this better than other ultra-microbalances?
Advanced automation, faster leveling, ambient light status indicators, and unmatched digital integration.

Can it be used in cleanroom environments?
Yes. It features automatic leveling, low draft influence, and minimal operator interaction for high-containment areas.

Order the Radwag UYA Ultra Microbalance from Lab Equipment Direct for industry-leading accuracy, smart lab features, and long-term reliability—ready to ship and backed by expert support.
