High-Torque Overhead Stirrer for Mixing Up to 100 Liters in High-Viscosity Laboratory Applications
The IKA EUROSTAR 200 Overhead Stirrer is engineered for high-viscosity mixing and heavy-duty lab applications up to 100 liters. This high-performance stirrer uses microprocessor-controlled speed adjustment, ensuring stable, accurate RPMs even when your sample’s viscosity changes. It also includes automatic overload protection and short-term overload operation.
Choose from the EUROSTAR 200 digital, EUROSTAR 200 control, or control P4 model, depending on your need for programmable functions, torque monitoring, USB/RS232 interfaces, and temperature measurement.
🔧 Key Features
-
Max capacity: Up to 100L (H₂O)
-
High torque: Up to 660 Ncm (Control P4)
-
Speed ranges:
-
Digital: 6–2000 RPM
-
Control P4: 4–530 RPM
-
-
Microprocessor-controlled speed regulation
-
Automatic overload protection
-
Error code display
-
Quiet and slim design
-
Push-through agitator shaft (not on Control P4)
-
2-year warranty
📊 Technical Specifications (Model Overview)
| Feature | Digital | Control | Control P4 |
|---|---|---|---|
| Max volume | 100 L | 100 L | 100 L |
| Torque max (Ncm) | 200 | 660 | 660 |
| Speed range (RPM) | 6–2000 | 6–2000 | 4–530 |
| Speed setting/display | Turning knob / LED | Touchpad / TFT | Touchpad / TFT |
| Viscosity max (mPas) | 100,000 | 100,000 | 150,000 |
| Programmable | No | Yes | Yes |
| Timer | No | Yes (1–6000 min) | Yes |
| External temp sensor | Not supported | PT1000 | PT1000 |
| Torque display | No | Yes | Yes |
| USB / RS232 | No | Yes | Yes |
| Housing material | Aluminum / Polymer | Aluminum / Polymer | Aluminum / Polymer |
| Stir bar fastening | Chuck | Chuck | Chuck |
| Chuck range | 0.5–10 mm | 0.5–10 mm | 0.5–10 mm |
| Hollow shaft | Yes | Yes | No |
| Dimensions (W × H × D, mm) | 91 × 274 × 209 | 91 × 297 × 231 | 91 × 379 × 231 |
| Weight (kg) | 4.6 | 4.9 | 5.8 |
| Voltage / Frequency | 230 / 100–115 V, 50/60 Hz | 230 / 100–115 V, 50/60 Hz | 230 / 100–115 V, 50/60 Hz |
| Power input | 130 W | 134 W | 134 W |
| Protection rating | IP40 | IP40 | IP40 |
| Ambient conditions | 5–40°C, ≤80% RH | 5–40°C, ≤80% RH | 5–40°C, ≤80% RH |
💡 Additional Notes
-
Push-through shafts allow fast agitator changes (excluding Control P4)
-
Integrated torque trend display helps monitor viscosity changes (Control models)
-
Control models support interval operation, temperature control, and external communication
🧪 FAQs
Q: Can I use this with flammable solvents or in clean rooms?
A: No. The EUROSTAR series is not explosion-proof and not clean-room qualified.
Q: Does the Control P4 allow viscosity trend monitoring?
A: Yes. It includes torque trend visualization for tracking sample viscosity in real-time.
