Fisher Anatomical Accu-Scope® Compound Microscope Bundle – Trinocular Head, DIN Achromatic 4X/10X/40XR/100XR Objectives, Double-Layer Mechanical Stage
Fisher Anatomical Accu-Scope® Compound Microscope Bundle – Trinocular Head, DIN Achromatic 4X/10X/40XR/100XR Objectives, Double-Layer Mechanical Stage is backordered and will ship as soon as it is back in stock.
Fisher Anatomical Accu-Scope® Compound Microscope Bundle – Trinocul...
SETTING UP A NEW LAB?
SAVE TIME AND MONEY—TALK TO A LAB EQUIPMENT EXPERT NOW!
Call us at 1 (888) 702-1513 for a FREE CONSULTATION and personalized quote.
Description
Description
The Accu-Scope® EXC-103-HDS Digital Microscope System, offered under Fisher Anatomical, provides robust optical quality and integrated HD imaging for laboratory and teaching applications.
Equipped with DIN Achromatic objectives (4X, 10X, 40XR, 100XR) and a trinocular head, this system pairs traditional clarity with digital versatility through the Excelis HD Lite 5 MP camera and monitor.
A double-layer mechanical stage, variable LED illumination, and durable cast-aluminum frame ensure long-term reliability for clinical, research, and instructional use.
✅ Key Features
- ✔️ Trinocular head, 30° inclined with 360° rotation for comfortable viewing and camera mounting
- ✔️ DIN Achromatic objectives (4X, 10X, 40XR, 100XR oil) for clear, color-accurate imaging
- ✔️ Excelis HD Lite camera (5 MP) with 0.5× adapter and built-in software for image capture and display
- ✔️ WF 10X/18 mm eyepieces, lockable with pointer for teaching and demonstration
- ✔️ Quadruple rear-facing nosepiece with positive click stops for precise alignment
- ✔️ Double-layer mechanical stage (115 × 125 mm) with vernier scale and right-hand controls
- ✔️ Coaxial coarse and fine focusing for smooth and accurate adjustment
- ✔️ N.A. 1.25 Abbe condenser with iris diaphragm for controlled illumination
- ✔️ Variable LED light source delivers bright, cool, energy-efficient illumination
- ✔️ Cast-aluminum stand with built-in carry handle and power-cord wrap
- ✔️ Universal power input (100–240 V AC) for global use
- ✔️ Includes dust cover, power cord, immersion oil, and manual
- ✔️ Manufactured by Fisher Anatomical / Accu-Scope®
📊 Technical Specifications
| Specification | Details |
|---|---|
| Brand | Accu-Scope® |
| Manufacturer | Fisher Anatomical |
| Manufacturer # | S012466 |
| Application | Compound Microscope Bundle |
| Head Type | Trinocular 30° Inclined, 360° Rotatable |
| Eyepieces | WF 10X/18 mm, Lockable with Pointer |
| Objectives | DIN Achromatic 4X, 10X, 40XR, 100XR (Oil) |
| Nosepiece | Quadruple Rear-Facing Ball-Bearing |
| Stage Type | Double-Layer Mechanical Stage |
| Stage Dimensions | 115 × 125 mm |
| Stage Controls | Right-Hand Low-Position with Vernier Scale |
| Condenser | Abbe N.A. 1.25 with Iris Diaphragm |
| Focus System | Coaxial Coarse and Fine Focus |
| Illumination | Variable LED Light Source |
| Camera System | Excelis HD Lite 5 MP Digital Camera + Monitor (0.5× Adapter) |
| Frame Construction | Cast Aluminum Alloy Stand with Handle |
| Power Source | 100–240 V AC Internal Power Supply |
| Dimensions (W×D×H) | 198 × 255 × 368 mm |
| Country of Origin | Unknown |
| UNSPSC Code | 41111759 |
| Warranty | 2 Years (Manufacturer Warranty) |
⚠️ Safety Notice
Before use, position the microscope on a stable, level surface. Connect only to a 100–240 V AC source using the supplied power cord. Avoid direct contact with optical lenses; use lens paper for cleaning. Keep liquids away from electrical components.
📚 Frequently Asked Questions (FAQs)
Does this microscope include a camera?
What objectives are included?
Is the illumination adjustable?
What type of stage does it use?
What makes the EXC-103-HDS ideal for teaching?
