Fisher Anatomical Accu-Scope® Compound Microscope Bundle – Trinocular, 4X/10X/20X Objectives,Fixed Plain Stage
Fisher Anatomical Accu-Scope® Compound Microscope Bundle – Trinocular, 4X/10X/20X Objectives,Fixed Plain Stage is backordered and will ship as soon as it is back in stock.
Fisher Anatomical Accu-Scope® Compound Microscope Bundle – Trinocul...
SETTING UP A NEW LAB?
SAVE TIME AND MONEY—TALK TO A LAB EQUIPMENT EXPERT NOW!
Call us at 1 (888) 702-1513 for a FREE CONSULTATION and personalized quote.
Description
Description
The Accu-Scope® Compound Microscope Bundle combines precision optics, ergonomic design, and integrated digital imaging for professional laboratory work. This EXI-410 Series Trinocular Microscope includes the Excelis HDS camera and monitor, providing real-time visualization, capture, and analysis capabilities ideal for tissue culture and advanced research applications.
Designed with a NIS60 infinity-corrected optical system, Plan Achromat and semi-Apochromatic objectives, and long working distance condensers, it offers bright, high-contrast images and comfortable usability for long observation sessions.
✅ Key Features
- ✔️ Trinocular head with WF 10X/22 mm eyepieces for wide-field observation and digital imaging integration
- ✔️ Plan Achromat and Semi-Apochromatic objectives (4X, 10X, 20X) for crisp, high-resolution imaging
- ✔️ NIS60 infinity-corrected optical system ensures superior optical clarity and long working distance performance
- ✔️ Integrated Excelis HDS digital camera system (available in 3 MP, 5 MP, or 7 MP options) with built-in display monitor
- ✔️ Ideal for tissue culture, live cell observation, and routine biological analysis
- ✔️ Coaxial coarse and fine focusing system, fine focus precision of 0.002 mm for sharp, accurate focusing
- ✔️ Focus range: 7 mm upward, 1.5 mm downward, total travel limit of 18.5 mm
- ✔️ LED illumination (3 W) for bright, consistent, and cool lighting
- ✔️ N.A. 0.3 condenser provides excellent light control and contrast
- ✔️ Fixed plain stage (170 × 250 mm) for stable sample support
- ✔️ Durable frame and smooth mechanical operation for long-term use
- ✔️ Made for professional laboratory, clinical, and academic applications
📊 Technical Specifications
| Specification | Details |
|---|---|
| Brand | Accu-Scope® |
| Manufacturer | Fisher Anatomical |
| Manufacturer # | 01189194 |
| Application | Compound Microscope Bundle |
| Head Type | Trinocular |
| Eyepieces | WF 10X/22 mm |
| Objectives | 4X, 10X, 20X (Plan Achromat/Semi-Apochromatic) |
| Optical System | NIS60 Infinity-Corrected |
| Condenser | N.A. 0.3 Condenser |
| Focus System | Coaxial Coarse & Fine (0.002 mm Precision) |
| Focus Range | 7 mm Up / 1.5 mm Down / 18.5 mm Total Travel |
| Stage Type | Fixed Plain Stage |
| Stage Dimensions (W×D) | 170 × 250 mm |
| Illumination | 3 W LED |
| Camera System | Excelis HDS (3 MP / 5 MP / 7 MP) |
| Dimensions (W×D×H) | 243 × 408 × 543 mm |
| Power Source | 100–240 V AC |
| Country of Origin | Unknown |
| UNSPSC Code | 41111759 |
| Warranty | 2 Years (Manufacturer Warranty) |
⚠️ Safety Notice
Before operation, place the microscope on a stable, level surface in a clean, ventilated environment. Connect only to a 100–240 V AC power source using the included cable. Avoid direct light into the eyepiece and do not handle optical components with bare hands.
📚 Frequently Asked Questions (FAQs)
What type of optical system does this microscope use?
What camera options are available?
What is the fine focus precision?
What type of condenser is included?
Can this microscope be used for tissue culture?
