Accu-Scope® Hematology Microscope – Trinocular Head, Plan Achromat 10X/40XR/50XR Oil/100XR Oil, Double-Layer Mechanical Stage
Accu-Scope® Hematology Microscope – Trinocular Head, Plan Achromat 10X/40XR/50XR Oil/100XR Oil, Double-Layer Mechanical Stage is backordered and will ship as soon as it is back in stock.
Accu-Scope® Hematology Microscope – Trinocular Head, Plan Achromat ...
SETTING UP A NEW LAB?
SAVE TIME AND MONEY—TALK TO A LAB EQUIPMENT EXPERT NOW!
Call us at 1 (888) 702-1513 for a FREE CONSULTATION and personalized quote.
Description
Description
The Accu-Scope® EXC-360-HEMA Hematology Microscope provides superior clarity, color accuracy, and ergonomic performance for hematology, cytology, and clinical diagnostic laboratories.
Built on the EXC-360 platform, it features Plan Achromat objectives optimized for oil immersion analysis, a trinocular head for digital imaging, and variable 3 W LED illumination for consistent, bright field lighting.
A rackless mechanical stage, coaxial focusing, and precision 50:50 light split ensure smooth workflow and reliable performance for detailed specimen evaluation.
✅ Key Features
- ✔️ Trinocular viewing head, 30° inclined and 360° rotatable for ergonomic use and camera attachment
- ✔️ Plan Achromat objectives (10X, 40XR, 50XR oil, 100XR oil) for flat, high-resolution imaging across the field of view
- ✔️ Fixed 50:50 light path split for simultaneous viewing through eyepieces and digital camera
- ✔️ PL 10X/22 mm focusable eyepieces with eye cushions for comfort during extended use
- ✔️ Rear-facing quintuple nosepiece on ball bearings with click stops for repeatable parcentration
- ✔️ Double-layer, rackless mechanical stage for smooth, precise slide movement
- ✔️ Slot for optional phase contrast or darkfield sliders for advanced applications
- ✔️ Coaxial coarse and fine focus controls with adjustable tension for precision focusing
- ✔️ 3 W variable LED illumination with field iris for optimal light control
- ✔️ 5 V USB charging port for powering small mobile devices
- ✔️ Includes dust cover, immersion oil, power cord, and instruction manual
- ✔️ Durable, compact construction for consistent performance in clinical environments
📊 Technical Specifications
| Specification | Details |
|---|---|
| Brand | Accu-Scope® |
| Manufacturer | Accu-Scope Inc. |
| Manufacturer # | EXC-360-HEMA |
| Application | Hematology Microscope |
| Head Type | Trinocular, 30° Inclined, 360° Rotatable |
| Eyepieces | PL 10X/22 mm Focusable with Eye Cushions |
| Objectives | Plan Achromat 10X, 40XR, 50XR Oil, 100XR Oil |
| Nosepiece | Quintuple, Rear-Facing, Ball Bearing |
| Condenser | Abbe N.A. 1.25 with Iris Diaphragm |
| Light Path Split | Fixed 50:50 (Eyepieces:Camera) |
| Stage Type | Double-Layer Rackless Mechanical Stage |
| Stage Dimensions (Approx.) | 215 × 314 mm |
| Illumination | 3 W Variable LED with Field Iris |
| Focus System | Coaxial Coarse & Fine Focus with Tension Adjustment |
| USB Port | 5 V USB Charging Port |
| Accessories | Power Cord, Dust Cover, Immersion Oil, Manual |
| Dimensions (W×D×H) | 215 × 314 × 416 mm |
| Power Source | 100–240 V AC (Internal Universal Supply) |
| Country of Origin | Unknown |
| UNSPSC Code | 41111759 |
| Warranty | 2 Years (Manufacturer Warranty) |
⚠️ Safety Notice
Place the microscope on a stable, level surface before operation. Connect only to a 100–240 V AC power source using the supplied cable. Avoid contact with optical surfaces and clean with lens paper only. Disconnect power before maintenance or cleaning. Do not block air vents during use. Follow Accu-Scope® safety and maintenance procedures for consistent, safe performance.
📚 Frequently Asked Questions (FAQs)
Is the LED illumination adjustable?
Can I use darkfield or phase contrast techniques?
What objectives are included with this hematology microscope?
Does it support digital imaging?
What type of stage is included?
