Accu-Scope® EXC-120 Series Compound Microscope – Trinocular Head, Achromat 4X/10X/40X/100X Oil Objectives, Double-Layer Mechanical Stage

The Accu-Scope® EXC-120 Series (Model EXC-123-HDS) combines optical precision, digital imaging capability, and durability for professional and classroom laboratories.
This microscope features Achromat 4X/10X/40X/100X oil objectives, a Seidentopf trinocular viewing head, and a double-layer mechanical stage for smooth, accurate specimen control.

It includes an Excelis HD Lite digital camera and attachable HD monitor, offering high-resolution imaging with standalone operation or PC connectivity via CaptaVision+ software. Built with a rugged die-cast aluminum frame, the EXC-120 Series is engineered for years of reliable performance.

✅ Key Features

• ✔️ Trinocular Seidentopf head, 30° inclined, interpupillary distance 48–75 mm

• ✔️ Achromat objectives (4X, 10X, 40X, 100X oil) deliver sharp, high-contrast imaging for clinical applications

• ✔️ Excelis HD Lite camera (5 MP) with attachable HD monitor and built-in software for PC-free operation

• ✔️ USB 2.0 connection for Windows PC control and image streaming via CaptaVision+ software

• ✔️ WF 10X/18.5 mm locked-in eyepieces, one with pointer to aid teaching and sample navigation

• ✔️ Quadruple rear-facing nosepiece with ball bearing movement and positive click stops for parcentration

• ✔️ Double-layer mechanical stage (150 × 139 mm) with 75 × 32 mm X–Y movement range and smooth slide control

• ✔️ Abbe condenser (N.A. 1.25) with iris diaphragm and filter holder

• ✔️ Variable LED illumination, pre-centered and rated for 20,000 hours of continuous use

• ✔️ Coaxial coarse and fine focusing system with metal gears and adjustable tension control

• ✔️ Die-cast aluminum frame ensures long-term stability and durability

• ✔️ Supports brightfield, phase contrast, darkfield, and simple polarization observation methods

• ✔️ Universal 110–240 V power supply, UL listed, with optional rechargeable LED base

• ✔️ Weighs 15 lbs

📊 Technical Specifications

⚠️ Safety Notice

Set the microscope on a stable, level surface before use. Connect only to a 110–240 V AC power source. Avoid direct sunlight and strong vibrations during operation. Use lens paper for optical cleaning and disconnect power before maintenance. Keep liquids away from electrical components. Follow Accu-Scope® EXC-120 Series operational guidelines for safe and reliable use.
